MST MH型號霍爾開關電路

服務項目：MST MH型號霍爾開關電路

點擊次數：25947 次

詳細信息：

東莞市愛多電子有限公司銷售臺灣MST MH各型號規格霍爾電路，產品質量穩定，交貨快捷，具體規格型號如下：

MH181，MH182，MH187，MH188，MH189，MH190，MH185，MH191，MH281，MH282，MH248，MH250，MH249，MH481，MH276，MH381，MH382，MH383，MH384，MH481，MH482.等型號。具體規格如下：

MST MH系列型號表
Ordering	Operation	Temperature(℃）	Package	Voltage	Output	Sensitivity	Status
Number	type	Temperature(℃）	Package	range	Current	(typ)	Status
MH181KUA	Latch	-20 to 125	TO 92S-3L	3.5V - 20V	25mA	90 Gauss	NOW
MH181EUA	Latch	-20 to 85	TO 92S-3L	3.5V - 20V	25mA	90 Gauss	NOW

MH182KUA	Latch	-40 to 125	TO 92S-3L	3V - 24V	50mA	60 Gauss	NOW
MH182KSO	Latch	-40 to 125	Sot23	3V - 24V	50mA	60 Gauss	NOW
MH182ESO	Latch	-40 to 85	Sot23	3V - 24V	50mA	60 Gauss	NOW

MH187KUA	Latch	-40 to 125	TO 92S-3L	3V - 24V	20mA	55 Gauss	NOW
MH187KSO	Latch	-40 to 125	Sot23	3V - 24V	20mA	55 Gauss	NOW
MH187EUA	Latch	-40 to 85	TO 92S-3L	3V - 24V	20mA	55 Gauss	NOW
MH187ESO	Latch	-40 to 85	Sot23	3V - 24V	20mA	55 Gauss	NOW
MH187ESQ	Latch	-40 to 85	QFN2020	3V - 24V	20mA	55 Gauss	NOW

MH188KUA	Latch	-40 to 125	TO 92S-3L	3V - 24V	20mA	60 Gauss	Now
MH188KSO	Latch	-40 to 125	Sot23	3V - 24V	20mA	60 Gauss	Now

MH189KUA	Latch	-40 to 125	TO 92S-3L	3V - 24V	50mA	40 Gauss	NOW
MH189KSO	Latch	-40 to 125	Sot23	3V - 24V	50mA	40 Gauss	NOW
MH189EUA	Latch	-40 to 85	TO 92S-3L	3V - 24V	50mA	40 Gauss	NOW
MH189ESO	Latch	-40 to 85	Sot23	3V - 24V	50mA	40 Gauss	NOW

MH190KUA	Latch	-40 to 125	TO 92S-3L	4V-30V	20mA	70 Gauss	NOW
MH190EUA	Latch	-40 to 85	TO 92S-3L	4V-30V	20mA	70 Gauss	NOW
MH190ESO	Latch	-40 to 85	Sot23	4V-30V	20mA	70 Gauss	NOW

MH185KUA	Latch	-40 to 125	TO 92S-3L	2.5V-5V	5mA	60 Gauss	NOW
MH185KSO	Latch	-40 to 125	Sot23	2.5V-5V	5mA	60 Gauss	NOW
MH185ESQ	Latch	-40 to 125	QFN2020	2.5V-5V	5mA	60 Gauss	NOW

MH192	Latch	E/K	UA/SO/SQ	1.65V-6V	25mA	60(30) Gauss	NOW

MH281KUA	Switch	-40 to 125	TO 92S-3L	3V - 24V	50mA	250(175) Gauss	NOW
MH281KSO	Switch	-40 to 125	Sot23	3V - 24V	50mA	250(175) Gauss	NOW
MH281ESO	Switch	-40 to 85	Sot23	3V - 24V	50mA	250(175) Gauss	NOW

MH282KUA	Switch	-40 to 125	TO 92S-3L	3V - 24V	50mA	100 Gauss	NOW
MH282KSO	Switch	-40 to 125	Sot23	3V - 24V	50mA	100 Gauss	NOW
MH282ESO	Switch	-40 to 85	Sot23	3V - 24V	50mA	100 Gauss	NOW

MH284	Switch	E/K	UA/SO	4.5V-30V	25mA	175 Gauss	Sampling

MH248EUA	Switch	-40 to 85	TO 92S-3L	2.5V - 3.5V	1mA	60 Gauss	NOW
MH248ESO	Switch	-40 to 85	Sot23	2.5V - 3.5V	1mA	60 Gauss	NOW
MH248ESQ	Switch	-40 to 85	QFN2020	2.5V - 3.5V	1mA	60 Gauss	NOW
MH248ESO	Switch	-40 to 85	Sot23	2.5V - 3.5V	1mA	60 Gauss	NOW
MH248ESO	Switch	-40 to 85	Sot23	2.5V - 3.5V	1mA	60 Gauss	NOW
MH248EST	Switch	-40 to 85	Sot23	2.5V - 3.5V	1mA	60 Gauss	NOW

MH250EUA	Switch	-40 to 85	TO 92S-3L	1.7V - 3.5V	1mA	40(30) Gauss	NOW
MH250ESO	Switch	-40 to 85	Sot23	1.7V - 3.5V	1mA	40(30) Gauss	NOW
MH250ESQ	Switch	-40 to 85	QFN2020	1.7V - 3.5V	1mA	40(30) Gauss	NOW
MH250EST	Switch	-40 to 85	Sot23	1.7V - 3.5V	1mA	40(30) Gauss	NOW

MH251	Switch	E	ST/SN/SQ/UA	1.65V -3.5V	1mA	55(30) Gauss	NOW
MH252	Switch	E	VK/SN	1.65V - 3.5V	1mA	50(30) Gauss	NOW
MH253	Switch	E/K	UA/SO/SQ	2.5V - 6V	25mA	60(30) Gauss	NOW

MH481EUA	Linear	-40 to 100	UA/SG/SQ	3V - 6.5V	4.5mA	2mV/Gauss	NOW
MH481EUA	Linear	-40 to 100	UA/SG/SQ	3V - 6.5V	4.5mA	2mV/Gauss	NOW

MH276EVK	Driver	-20 to 85	TO 92S-4L	3.5V-20V	500mA	50/70/100 Gauss	NOW
MH276EVK	Driver	-20 to 85	TO 92S-4L	3.5V-20V	500mA	50/70/100 Gauss	NOW
MH276EVK	Driver	-20 to 85	TO 92S-4L	3.5V-20V	500mA	50/70/100 Gauss	NOW

MH477	Driver	E	VK	3.5V-20V	350mA	70/100/130 Gauss	NOW
MH477S	Driver	E	VK	3.5V-20V	200mA	70/100/130 Gauss	NOW
MH381/381F/381R	Driver	E/K	VK/VF/SF	2.5V-20V	600mA	40(20) Gauss	NOW
MH382/382F/382R	Driver	E/K	VK/VF/SF	4.5V-30V	300mA	40(20) Gauss	NOW
